Door Type Vertical Vacuum Packing Machine

Model No: VCD 450/550/700
SEALING LENGTH 450/550/700mm
SEALING WIDTH 10mm
SEALING BARS 1no(2ND OPTIONAL)
CHAMBER SIZE AS PER MODEL
MACHINE CYCLE TIME 20-40SEC
CONTROLLER TIMER BASED
CONTROL CABLES RR CABLES
SWITCHGEAR Schneider
POWER SUPPLY 1 Phase 230v/3PHASE 415V 50HZ
POWER KW 1.2 -2.2 kw
MACHINE WEIGHT 100/190/240KG
PUMP CAPACITY 16-40 m3/hr. (INDIAN MAKE)
MACHINE DIMENSIONS L570 X W550 X H750mm
MACHINE MOC SS 304
  • Heavy duty door type chamber vacuum packing machine suitable for Flour, Semi liquid, Pulses, spices, herbal extracts powder, Dry fruits and any kind of powder & granules materials.
  • Adjustable product platform suitable for 100 grams to 25 KG product packing
  • Rema Make timer-based control panel for easy adjustment of vacuum time, sealing time, etc.
  • Stainless steel body, no sharp edges, use cast aluminum & other nonferrous materials to safe rust issue and easy cleaning.
  • Insert gas flushing unit.
  • PLC Based Control Panel with touch LCD display for adjustment of accurate vacuum & gas pressure.
  • BUSCH or BECKER (German Make) Vacuum Pump.
  • Mold and Formers as per require packing size
